Product Summary
The J505 is a current regulator designed for demanding applications in test equipment and instrumentation. The J505 utilizes the JFET techniques to produce a single two-leaded device which is extremely simple to operate. With nominal current ranges from 0.24 mA to 4.7 mA, the J505 will meet a wide array of design requirements. The low-cost TO-226A package ensures a cost-effective design solution. The applications of it are Constant-Current Supply, Current-Limiting, Timing Circuits.
Parametrics
J505 absolute maximum ratings: (1)Peak Operating Voltage:50 V; (2)Reverse Current:50 mA; (3)Storage Temperature:–55 to 150℃; (4)Power Dissipationa:350 mW.
Features
J505 features: (1)Two-Lead PlasticPackage; (2)Guaranteed ±20% Tolerance; (3)Operation from 1 V (J500–J503) to 50 V; (4)Excellent Temperature Stability.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 J505-E3 |
Vishay/Siliconix |
Current Regulator Diodes 1.0mA +/-20% |
Data Sheet |
Negotiable |
|
||||
|
J505 |
Vishay/Siliconix |
Current & Power Monitors & Regulators 1.0mA +/-20% |
Data Sheet |
Negotiable |
|
||||
