Product Summary
The HT7022 is a three-terminal low power voltage detector implemented in CMOS technology. The HT7022 detects a particular fixed voltage 2.2V. The voltage detector consists of a high-precision and low power consumption standard voltage source, a comparator, hysteresis circuit, and an output driver. CMOS technology ensures low power consumption. The applications of the HT7022 are Battery checkers, Power failure detectors, Microcomputer reset, Battery memory backup, Non-volatile RAM signal storage protectors.
Parametrics
HT7022 absolute maximum ratings: (1)Supply Voltage:VSS-0.3V to VSS+13V; (2)Output Voltage:VSS-0.3V to VDD+0.3V; (3)Output Current:50mA; (4)Storage Temperature:-50℃ to 125℃; (5)Power Consumption:200mW; (6)Operating Temperature:-40℃ to 85℃.
Features
HT7022 features: (1)Low detectable voltage 2.2V; (2)Low power consumption; (3)Low temperature coefficient; (4)Built-in high-stability reference source; (5)Built-in hysteresis characteristic; (6)TO-92 and SOT-89 package.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
HT7022A-1 |
Other |
Data Sheet |
Negotiable |
|
||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
HT70 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7022A-1 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7024A |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7024A-1 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7024B |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7027A-1 |
Other |
Data Sheet |
Negotiable |
|
